VDM-SERIES
|
VDM-Series |
|
250 |
550 |
800 |
1000 |
1600 |
2000 |
|
Working area |
|
|
|
|
|
|
|
|
max. Turning-ø |
mm |
200 |
600 |
800 |
1150 |
1600 |
1800 |
|
max. Swing-ø |
mm |
250 |
680 |
900 |
1450 |
1800 |
1950 |
|
workpiece height(chuck+workpiec.) |
mm |
800 |
600 |
750 |
1000 |
1000 Optional 1600 |
830 Optional 2000 |
|
Axes |
|
|
|
|
|
|
|
|
rapid traverse - Z Axis |
m/min |
30 |
30 |
20 |
20 |
20 |
20 |
|
rapid traverse - X Axis |
m/min |
30 |
60 |
25 |
25 |
20 |
20 |
|
Main spindle |
|
|
|
|
|
|
|
|
max. Power [40%] |
kW |
36 |
80 |
160 |
84 |
165 |
165 |
|
max. Torque [40%] |
Nm |
384 |
1150 |
6370 |
25877 |
49500 |
49500 |
|
max. Speed |
min-1 |
5500 |
2800 |
1200 |
630 |
400 |
400 |
|
Tool carrier |
|
|
|
|
|
|
|
|
driven tools |
|
ü |
ü |
ü |
|
|
|
|
numbers |
|
2x12 |
12 |
12 |
12 |
12 |
12 |
|
Tool system VDI 69880 |
mm |
40 |
50 |
50 |
50 |
60 |
60 |
